OTTIMA OTM-TD12 Constant Current Triac Dimming LED Driver, 350mA 24-36V 12W

Product image 1
1 / 5

OTTIMA OTM-TD12 Constant Current Triac Dimming LED Driver, 350mA 24-36V 12W

Model OTM-TD12
Input Voltage 90-130V AC
Input Current 0.15A
Input Frequency 48-62Hz
Power Factor PF>0.95
Efficiency >85%
Output Regulated Current 350mA
Output Power 12W
Output Voltage 24-36V DC
Dimmable Yes (Triac Dimming)
Ambient Temperature (Ta) 40°C
Case Temperature (Tc) 90°C
IP Rating IP20 (Indoor use only)
Dimensions 94 x 36 x 18.5 mm (3.7 x 1.42 x 0.72 in)
Class Certification Class II
Certification




Features:

  • OTTIMA OTM-TD12 Constant Current LED Driver
  • Model number: OTM-TD12
  • Input voltage range: 90-130V AC, input current: 0.15A, frequency range: 48-62Hz
  • High power factor (PF > 0.95) and efficiency (>85%)
  • Regulated output current: 350mA, output power: 12W
  • Output voltage range: 24-36V DC
  • Dimmable with Triac Dimming for adjustable brightness
  • Ambient temperature (Ta): 40°C, case temperature (Tc): 90°C
  • IP20 rating for indoor use
  • Compact dimensions: 94 x 36 x 18.5 mm (3.7 x 1.42 x 0.72 in)
  • Class II certification for double insulation and no grounding wire required
  • Reliable and efficient solution for powering LED lights indoors with a constant current of 350mA and an output voltage range of 24-36V DC.
$8.15

Original: $27.17

-70%
OTTIMA OTM-TD12 Constant Current Triac Dimming LED Driver, 350mA 24-36V 12W—

$27.17

$8.15

Product Information

Shipping & Returns

Description

Model OTM-TD12
Input Voltage 90-130V AC
Input Current 0.15A
Input Frequency 48-62Hz
Power Factor PF>0.95
Efficiency >85%
Output Regulated Current 350mA
Output Power 12W
Output Voltage 24-36V DC
Dimmable Yes (Triac Dimming)
Ambient Temperature (Ta) 40°C
Case Temperature (Tc) 90°C
IP Rating IP20 (Indoor use only)
Dimensions 94 x 36 x 18.5 mm (3.7 x 1.42 x 0.72 in)
Class Certification Class II
Certification




Features:

  • OTTIMA OTM-TD12 Constant Current LED Driver
  • Model number: OTM-TD12
  • Input voltage range: 90-130V AC, input current: 0.15A, frequency range: 48-62Hz
  • High power factor (PF > 0.95) and efficiency (>85%)
  • Regulated output current: 350mA, output power: 12W
  • Output voltage range: 24-36V DC
  • Dimmable with Triac Dimming for adjustable brightness
  • Ambient temperature (Ta): 40°C, case temperature (Tc): 90°C
  • IP20 rating for indoor use
  • Compact dimensions: 94 x 36 x 18.5 mm (3.7 x 1.42 x 0.72 in)
  • Class II certification for double insulation and no grounding wire required
  • Reliable and efficient solution for powering LED lights indoors with a constant current of 350mA and an output voltage range of 24-36V DC.
